LR50/82RSR
Tier-one manufacturer — brand supplied may vary ✓ Dimensions confirmed by two independent sourcesRegular price
$35.20 USD
Regular price
Sale price
$35.20 USD
Unit price
per
Couldn't load pickup availability
Bore8 mm
0.315 in
Outside dia.24 mm
0.9449 in
Width11 mm
0.4331 in
TypeYoke-type track roller, double row
SealingDouble Sealed
Flat-rate shipping — calculated by weight at checkout
Image is for illustration purposes only.
LR50/82RSR specifications
| Specification | Metric | Inch | Basis |
|---|---|---|---|
| Bore (d) | 8 mm | 0.315 in | Two independent catalogue sources agree |
| Outside diameter (D) | 24 mm | 0.9449 in | Two independent catalogue sources agree |
| Width (B) | 11 mm | 0.4331 in | Two independent catalogue sources agree |
| Bearing type | Yoke-type track roller, double row | Stated by the designation | |
| Seals / shields | Double Sealed | Supplier catalogue listing | |
LR50/82RSR is a yoke-type track roller, double row, 8 mm bore × 24 mm OD × 11 mm wide (0.315 × 0.9449 × 0.4331 in).
The LR50/8-2RSR is a track roller bearing featuring double rubber seals (2RSR) for protection against contaminants in demanding operating environments. Track roller bearings are designed with a thick-walled outer ring to run directly on track surfaces without requiring an additional raceway.
LR50/8-2RSR Track Rollers Series Bearing
Measurement Type
Metric
Inner Diameter (ID)
8 mm
Outside Diameter (OD)
24 mm
Width
11 mm
Sealing
Double Sealed
Precision Class
ABEC 1 | ISO P0
Other Features
Track Roller Bearing | Thick Outer Ring | Radial Load Design
Component
Assembly
Weight (kg)
0.03
Basic Number
LR50/8
UNSPSC
31171530
