Image is for illustration purposes only.
BL209NR
The BL209NR is a single row radial ball bearing with an open design and snap ring groove. This bearing features no seals or shields, allowing for external lubrication and higher speed capabilities, while the snap ring enables secure axial positioning in the housing.
Single row radial ball bearings are widely used in electric motors, gearboxes, pumps, and general industrial equipment where radial and light thrust loads are present. The open type design is ideal for applications with oil bath or circulating lubrication systems.
Interchange / cross reference
TIMKEN 1209L
Cross-references are provided as a guide — verify dimensions and fit for your application.
BL209NR Bl200 Max Type Ball Bearing
For large orders ($2000+) please inquire by email.
Measurement Type
Metric
Inner Diameter (ID)
45 mm
Outside Diameter (OD)
85 mm
Width
19 mm
Sealing
Open
Precision Class
ABEC 1 | ISO P0
Bearing Type
Max Type Ball Bearing
Other Features
Single Row | Deep Groove Ball Bearing
Component
Assembly
Weight (kg)
0.44
Basic Number
209
UNSPSC
31171504
