Image is for illustration purposes only.
30218M-90KM1
The 30218M-90KM1 is a metric tapered roller bearing assembly featuring a 90mm tapered bore (1:12 ratio) in the 302 series. This matched assembly configuration is designed to ISO 355 standards and provides proper preload for optimal performance in applications requiring radial and axial load capacity.
Tapered roller bearings are commonly used in automotive wheel hubs, gearboxes, industrial gearsets, and heavy machinery where combined loading conditions exist. The tapered bore design facilitates mounting on tapered shafts or adapter sleeves for secure positioning and easy installation.
30218M-90KM1 TRB Metric Assembly 4-8 OD
For large orders ($2000+) please inquire by email.
Measurement Type
Metric
Inner Diameter (ID)
90 mm
Outside Diameter (OD)
160 mm
Width
32.5 mm
Sealing
Open
Precision Class
ISO P0
Arrangement
Matched bearing assembly
Series
302
Bearing Type
Tapered roller bearing
Other Features
Single Row | Tapered Roller Bearing
Component
Assembly
Number of Tapered Rows
1
Weight (kg)
2.63
Basic Number
30218M
UNSPSC
31171516
