HK1616B.AS1
Tier-one manufacturer — brand supplied may vary ✓ Dimensions checked: ISO table and supplier data agreeCouldn't load pickup availability
Image is for illustration purposes only.
HK1616B.AS1 specifications
| Specification | Metric | Inch | Basis |
|---|---|---|---|
| Bore (d) | 16 mm | 0.6299 in | ISO table for this designation, confirmed by supplier data |
| Outside diameter (D) | 22 mm | 0.8661 in | ISO table for this designation, confirmed by supplier data |
| Width (B) | 16 mm | 0.6299 in | ISO table for this designation, confirmed by supplier data |
| Bearing type | Drawn cup needle roller bearing, open ends | Stated by the designation | |
| Seals / shields | Open | Supplier catalogue listing | |
| Cage | Pressed Steel | Supplier catalogue listing | |
Equivalent to / interchanges with
Also listed in manufacturer interchange tables (1): confirm suffix codes before ordering
- SKF HK1616 (SKF Master Interchange)
These carry maker-specific suffix codes (cage, lubrication groove, design) that we have not matched one-for-one. The size is the same; check the codes against your application.
Equivalents are dimensional and closure-for-closure: same bore, outside diameter, width, seals or shields and internal clearance. Bearing interchange tables
HK1616B.AS1 is a drawn cup needle roller bearing, open ends, 16 mm bore × 22 mm OD × 16 mm wide (0.6299 × 0.8661 × 0.6299 in).
The HK1616B.AS1 is a drawn cup needle roller bearing with an open design, cage to guide the rollers, and an integrated oil hole for lubrication access. This bearing features a thin-walled outer ring drawn from sheet steel, with precision needle rollers retained by a cage, providing high radial load capacity in a compact radial space.
