5308-ZZ

Tier-one manufacturer — brand supplied may vary ✓ Dimensions checked: ISO table and supplier data agree
$68.33 USD
$68.33 USD
Sale Sold out
Bore40 mm 1.5748 in
Outside dia.90 mm 3.5433 in
Width36.51 mm 1.4375 in
TypeDouble row angular contact ball bearing
SealingMetal shields, both sides
ClearanceNormal
Flat-rate shipping — calculated by weight at checkout
  • 5308-ZZ Ball Bearings
1 1

Image is for illustration purposes only.

What 5308-ZZ means

CodePositionMeaning
53 Series Series 53: angular contact ball bearing, double row, diameter series 3 (medium)
08 Bore Bore code 08 × 5 = 40 mm
ZZ Closure Metal shields, both sides

Read from the ISO / ABMA numbering rules and the makers' published suffix conventions. Decode any other number with the bearing number decoder.

5308-ZZ specifications

Specification Metric Inch Basis
Bore (d) 40 mm 1.5748 in ISO table for this designation, confirmed by supplier data
Outside diameter (D) 90 mm 3.5433 in ISO table for this designation, confirmed by supplier data
Width (B) 36.51 mm 1.4375 in Maker's catalogue (PEER Bearing), confirmed by supplier data
Bearing type Double row angular contact ball bearing Stated by the designation
Seals / shields Metal shields, both sides Stated by the designation
Internal clearance Normal (CN): no clearance code in the designation Stated by the designation
Tolerance class Normal (ISO P0 / ABEC 1): no tolerance-class code Stated by the designation

5308-ZZ is a double row angular contact ball bearing, 40 mm bore × 90 mm OD × 36.51 mm wide (1.5748 × 3.5433 × 1.4375 in). It has metal shields on both sides.

The 5308-ZZ is a double row angular contact ball bearing with a 40mm bore diameter and metal shields on both sides. The ZZ designation indicates the metal shield enclosure that protects the bearing from contaminants while retaining lubrication.

5308 ZZ 5300 Series Double Row Ball Bearing
