5305-2RS
Tier-one manufacturer — brand supplied may vary ✓ Dimensions checked: ISO table and supplier data agreeRegular price
$35.20 USD
Regular price
Sale price
$35.20 USD
Unit price
per
Couldn't load pickup availability
Bore25 mm
0.9843 in
Outside dia.62 mm
2.4409 in
Width25.4 mm
1 in
TypeDouble row angular contact ball bearing
SealingContact rubber seals, both sides
ClearanceNormal
Ships from US partner stock — flat-rate shipping, calculated by weight at checkout
Image is for illustration purposes only.
What 5305-2RS means
| Code | Position | Meaning |
|---|---|---|
53 |
Series | Series 53: angular contact ball bearing, double row, diameter series 3 (medium) |
05 |
Bore | Bore code 05 × 5 = 25 mm |
2RS |
Closure | Contact rubber seals, both sides |
Read from the ISO / ABMA numbering rules and the makers' published suffix conventions. Decode any other number with the bearing number decoder.
5305-2RS specifications
| Specification | Metric | Inch | Basis |
|---|---|---|---|
| Bore (d) | 25 mm | 0.9843 in | ISO table for this designation, confirmed by supplier data |
| Outside diameter (D) | 62 mm | 2.4409 in | ISO table for this designation, confirmed by supplier data |
| Width (B) | 25.4 mm | 1 in | Maker's catalogue (PEER Bearing), confirmed by supplier data |
| Bearing type | Double row angular contact ball bearing | Stated by the designation | |
| Seals / shields | Contact rubber seals, both sides | Stated by the designation | |
| Internal clearance | Normal (CN): no clearance code in the designation | Stated by the designation | |
| Tolerance class | Normal (ISO P0 / ABEC 1): no tolerance-class code | Stated by the designation | |
5305-2RS is a double row angular contact ball bearing, 25 mm bore × 62 mm OD × 25.4 mm wide (0.9843 × 2.4409 × 1 in). It has rubber contact seals on both sides.
The 5305-2RS is an angular contact ball bearing with a 25mm bore diameter, featuring contact rubber seals on both sides for protection against contaminants. This double row design provides increased load capacity and rigidity compared to single row configurations.
5305-2RS 5300 Series Double Row Ball Bearing
Measurement Type
Metric
Inner Diameter (ID)
25 mm
Outside Diameter (OD)
62 mm
Width
25.4 mm
Sealing
Double Sealed
Precision Class
ABEC 1 | ISO P0
Series
53
Bearing Type
Angular contact ball bearing
Other Features
Double Row | Ball Bearing | Radial Load Design
Component
Assembly
Weight (kg)
0.32
Basic Number
5305
UNSPSC
31171504
