5304-2RS

Tier-one manufacturer — brand supplied may vary ✓ Dimensions checked: ISO table and supplier data agree
$29.31 USD
$29.31 USD
Sale Sold out
Bore20 mm 0.7874 in
Outside dia.52 mm 2.0472 in
Width22.23 mm 0.875 in
TypeDouble row angular contact ball bearing
SealingContact rubber seals, both sides
ClearanceNormal
Ships from US partner stock — flat-rate shipping, calculated by weight at checkout
  • 5304-2RS Ball Bearings
1 1

Image is for illustration purposes only.

What 5304-2RS means

CodePositionMeaning
53 Series Series 53: angular contact ball bearing, double row, diameter series 3 (medium)
04 Bore Bore code 04 × 5 = 20 mm
2RS Closure Contact rubber seals, both sides

Read from the ISO / ABMA numbering rules and the makers' published suffix conventions. Decode any other number with the bearing number decoder.

5304-2RS specifications

Specification Metric Inch Basis
Bore (d) 20 mm 0.7874 in ISO table for this designation, confirmed by supplier data
Outside diameter (D) 52 mm 2.0472 in ISO table for this designation, confirmed by supplier data
Width (B) 22.23 mm 0.875 in Maker's catalogue (PEER Bearing), confirmed by supplier data
Bearing type Double row angular contact ball bearing Stated by the designation
Seals / shields Contact rubber seals, both sides Stated by the designation
Internal clearance Normal (CN): no clearance code in the designation Stated by the designation
Tolerance class Normal (ISO P0 / ABEC 1): no tolerance-class code Stated by the designation

5304-2RS is a double row angular contact ball bearing, 20 mm bore × 52 mm OD × 22.23 mm wide (0.7874 × 2.0472 × 0.875 in). It has rubber contact seals on both sides.

The 5304-2RS is a double row angular contact ball bearing with a 20 mm bore diameter and contact rubber seals on both sides. The dual row configuration provides increased radial and axial load capacity compared to single row designs, while the seals protect internal components from contamination.
