5209-2RS

Tier-one manufacturer — brand supplied may vary ✓ Dimensions checked: ISO table and supplier data agree
$56.76 USD
$56.76 USD
Sale Sold out
Bore45 mm 1.7717 in
Outside dia.85 mm 3.3465 in
Width30.16 mm 1.1875 in
TypeDouble row angular contact ball bearing
SealingContact rubber seals, both sides
ClearanceNormal
Ships from US partner stock — flat-rate shipping, calculated by weight at checkout
1 1

Image is for illustration purposes only.

What 5209-2RS means

CodePositionMeaning
52 Series Series 52: angular contact ball bearing, double row, diameter series 2 (light)
09 Bore Bore code 09 × 5 = 45 mm
2RS Closure Contact rubber seals, both sides

Read from the ISO / ABMA numbering rules and the makers' published suffix conventions. Decode any other number with the bearing number decoder.

5209-2RS specifications

Specification Metric Inch Basis
Bore (d) 45 mm 1.7717 in ISO table for this designation, confirmed by supplier data
Outside diameter (D) 85 mm 3.3465 in ISO table for this designation, confirmed by supplier data
Width (B) 30.16 mm 1.1875 in Maker's catalogue (PEER Bearing), confirmed by supplier data
Bearing type Double row angular contact ball bearing Stated by the designation
Seals / shields Contact rubber seals, both sides Stated by the designation
Internal clearance Normal (CN): no clearance code in the designation Stated by the designation
Tolerance class Normal (ISO P0 / ABEC 1): no tolerance-class code Stated by the designation

5209-2RS is a double row angular contact ball bearing, 45 mm bore × 85 mm OD × 30.16 mm wide (1.7717 × 3.3465 × 1.1875 in). It has rubber contact seals on both sides.

The 5209-2RS is a double row angular contact ball bearing with a 45 mm bore diameter and contact rubber seals on both sides. The seals provide protection against contamination while retaining lubrication for extended service life.

5209-2RS 5200 Series Double Row Ball Bearing
