5205-2RS
Tier-one manufacturer — brand supplied may vary ✓ Dimensions checked: ISO table and supplier data agreeCouldn't load pickup availability
Image is for illustration purposes only.
What 5205-2RS means
| Code | Position | Meaning |
|---|---|---|
52 |
Series | Series 52: angular contact ball bearing, double row, diameter series 2 (light) |
05 |
Bore | Bore code 05 × 5 = 25 mm |
2RS |
Closure | Contact rubber seals, both sides |
Read from the ISO / ABMA numbering rules and the makers' published suffix conventions. Decode any other number with the bearing number decoder.
5205-2RS specifications
| Specification | Metric | Inch | Basis |
|---|---|---|---|
| Bore (d) | 25 mm | 0.9843 in | ISO table for this designation, confirmed by supplier data |
| Outside diameter (D) | 52 mm | 2.0472 in | ISO table for this designation, confirmed by supplier data |
| Width (B) | 20.64 mm | 0.8125 in | Maker's catalogue (PEER Bearing), confirmed by supplier data |
| Bearing type | Double row angular contact ball bearing | Stated by the designation | |
| Seals / shields | Contact rubber seals, both sides | Stated by the designation | |
| Internal clearance | Normal (CN): no clearance code in the designation | Stated by the designation | |
| Tolerance class | Normal (ISO P0 / ABEC 1): no tolerance-class code | Stated by the designation | |
5205-2RS is a double row angular contact ball bearing, 25 mm bore × 52 mm OD × 20.64 mm wide (0.9843 × 2.0472 × 0.8125 in). It has rubber contact seals on both sides.
The 5205-2RS is an angular contact ball bearing from the 52 series, featuring a 25 mm bore diameter and contact rubber seals on both sides. The double row design provides increased radial and axial load capacity compared to single row configurations, while the seals protect against contamination in moderate operating environments.
5205-2RS 5200 Series Double Row Ball Bearing
