22209-C3
Tier-one manufacturer — brand supplied may vary ✓ Bore checked against the ISO tableCouldn't load pickup availability
Ships from our European partner stock — allow 5–8 business days
Image is for illustration purposes only.
What 22209-C3 means
| Code | Position | Meaning |
|---|---|---|
2 |
Type | Spherical roller bearing |
2 |
Width series | Width series 2 |
2 |
Diameter series | Diameter series 2 (light) |
09 |
Bore | Bore code 09 × 5 = 45 mm |
C3 |
Internal clearance | C3: radial internal clearance greater than Normal |
Read from the ISO / ABMA numbering rules and the makers' published suffix conventions. Decode any other number with the bearing number decoder.
22209-C3 specifications
| Specification | Metric | Inch | Basis |
|---|---|---|---|
| Bore (d) | 45 mm | 1.7717 in | ISO table for this designation, confirmed by supplier data |
| Outside diameter (D) | 85 mm | 3.3465 in | Supplier catalogue listing |
| Width (B) | 23 mm | 0.9055 in | Supplier catalogue listing |
| Bearing type | Spherical roller bearing | Stated by the designation | |
| Seals / shields | Open (no seals or shields) | Stated by the designation | |
| Internal clearance | C3 (greater than Normal) | Stated by the designation | |
| Bore | Cylindrical (straight) bore | Stated by the designation | |
| Tolerance class | Normal (ISO P0 / ABEC 1): no tolerance-class code | Stated by the designation | |
Equivalent to / interchanges with
| Brand | Part number | Basis |
|---|---|---|
| SKF | 22209E/C3 | NTN spherical roller bearing interchange |
Also listed in manufacturer interchange tables (5): confirm suffix codes before ordering
- SKF 22209ECA/C3 (NTN spherical roller bearing interchange)
- TIMKEN 22209EJW33C3 (NTN spherical roller bearing interchange)
- FAG 22209-E1--C3 (NTN spherical roller bearing interchange)
- NSK 22209EAE4C3 (NTN spherical roller bearing interchange)
- NTN 22209EAW33C3 (NTN spherical roller bearing interchange)
These carry maker-specific suffix codes (cage, lubrication groove, design) that we have not matched one-for-one. The size is the same; check the codes against your application.
Equivalents are dimensional and closure-for-closure: same bore, outside diameter, width, seals or shields and internal clearance. Bearing interchange tables
22209-C3 is a spherical roller bearing, 45 mm bore × 85 mm OD × 23 mm wide (1.7717 × 3.3465 × 0.9055 in). It has C3 internal clearance. Published interchange tables list it as equivalent to SKF 22209E/C3.
The 22209-C3 is a spherical roller bearing with a 45 mm bore diameter from the 222 series. It features C3 radial internal clearance, which is greater than normal clearance, making it suitable for applications with thermal expansion or shaft deflection requirements.
