16002
Tier-one manufacturer — brand supplied may vary ✓ Dimensions checked: ISO table and supplier data agreeCouldn't load pickup availability
Image is for illustration purposes only.
What 16002 means
| Code | Position | Meaning |
|---|---|---|
160 |
Series | Series 160: deep groove ball bearing, narrower than the 60-series equivalent of the same bore |
02 |
Bore | Bore code 02 = 15 mm (codes 00, 01, 02 and 03 are fixed at 10, 12, 15 and 17 mm) |
Read from the ISO / ABMA numbering rules and the makers' published suffix conventions. Decode any other number with the bearing number decoder.
16002 specifications
| Specification | Metric | Inch | Basis |
|---|---|---|---|
| Bore (d) | 15 mm | 0.5906 in | ISO table for this designation, confirmed by supplier data |
| Outside diameter (D) | 32 mm | 1.2598 in | Maker's catalogue (PEER Bearing), confirmed by supplier data |
| Width (B) | 8 mm | 0.315 in | Maker's catalogue (PEER Bearing), confirmed by supplier data |
| Bearing type | Deep groove ball bearing | Stated by the designation | |
| Seals / shields | Open (no seals or shields) | Stated by the designation | |
| Internal clearance | Normal (CN): no clearance code in the designation | Stated by the designation | |
| Tolerance class | Normal (ISO P0 / ABEC 1): no tolerance-class code | Stated by the designation | |
Equivalent to / interchanges with
| Brand | Part number | Basis |
|---|---|---|
| SKF | 16002 | Brand suffix convention for this ISO size |
| TIMKEN | 16002 | Brand suffix convention for this ISO size |
| FAG | 16002 | Brand suffix convention for this ISO size |
| NSK | 16002 | Brand suffix convention for this ISO size |
| NTN | 16002 | Brand suffix convention for this ISO size |
| KOYO | 16002 | Brand suffix convention for this ISO size |
| NACHI | 16002 | Brand suffix convention for this ISO size |
Equivalents are dimensional and closure-for-closure: same bore, outside diameter, width, seals or shields and internal clearance. Bearing interchange tables
16002 is a deep groove ball bearing, 15 mm bore × 32 mm OD × 8 mm wide (0.5906 × 1.2598 × 0.315 in). It has no seals or shields (open). Other makers sell the same size as SKF 16002, TIMKEN 16002, FAG 16002, NSK 16002.
The 16002 is a deep groove ball bearing with a 15 mm bore diameter from the 160 series. This open-type bearing has no seals or shields, allowing for maximum speed capability and easy lubrication maintenance in appropriate environments.
Bore/Inner Diameter Inch: 0.591
Bore/Inner Diameter mm: 15
Seal Type: Open
