SBX0437C3
The SBX0437C3 is a ball bearing insert designed for mounted bearing applications. Insert bearings feature a spherical outer diameter that fits into a corresponding housing, providing easy installation and self-aligning capability to compensate for shaft misalignment.
Insert bearings are commonly used in agricultural equipment, conveyor systems, material handling equipment, and general industrial machinery where reliable shaft support and ease of maintenance are required. The C3 suffix indicates C3 internal clearance for applications involving thermal expansion or shaft deflection.
For large orders ($2000+) please inquire by email.
Measurement Type
Metric
Inner Diameter (ID)
19 mm
Outside Diameter (OD)
42 mm
Width
24.6 mm
Sealing
Open
Precision Class
ABEC 1 | ISO P0
Ball Material
Ball
Other Features
Single Row | Deep Groove Ball Bearing
Component
Assembly
Weight (kg)
0.13
Basic Number
SBX0437
UNSPSC
31171504
