NA2205.2RS
Tier-one manufacturer — brand supplied may vary ✓ Bore checked against the ISO tableRegular price
$100.61 USD
Regular price
Sale price
$100.61 USD
Unit price
per
Couldn't load pickup availability
Bore25 mm
0.9843 in
Outside dia.52 mm
2.0472 in
Width18 mm
0.7087 in
TypeNeedle roller bearing with inner ring
SealingContact rubber seals, both sides
Flat-rate shipping — calculated by weight at checkout
Image is for illustration purposes only.
NA2205.2RS specifications
| Specification | Metric | Inch | Basis |
|---|---|---|---|
| Bore (d) | 25 mm | 0.9843 in | ISO table for this designation, confirmed by supplier data |
| Outside diameter (D) | 52 mm | 2.0472 in | Supplier catalogue listing |
| Width (B) | 18 mm | 0.7087 in | Supplier catalogue listing |
| Bearing type | Needle roller bearing with inner ring | Stated by the designation | |
| Seals / shields | Contact rubber seals, both sides | Stated by the designation | |
| Material | Needle bearing | Supplier catalogue listing | |
NA2205.2RS is a needle roller bearing with inner ring, 25 mm bore × 52 mm OD × 18 mm wide (0.9843 × 2.0472 × 0.7087 in). It has rubber contact seals on both sides.
The NA2205.2RS is a track roller bearing with double rubber seals (2RS) designed to run directly on tracks or guide rails. This support roller bearing features an integral stud design for yoke-type mounting applications, with seals on both sides to protect against contaminant ingress.
Measurement Type
Metric
Inner Diameter (ID)
25 mm
Outside Diameter (OD)
52 mm
Width
18 mm
Sealing
Double Sealed
Precision Class
ISO P0
Ball Material
Needle Bearing
Bearing Type
Cam Follower and Track Roller - Yoke Type
Other Features
Track Roller Bearing | Thick Outer Ring | Radial Load Design
Component
Assembly
Weight (kg)
0.2
Basic Number
NA2205
UNSPSC
31171530
