HK5024.-2RS
Tier-one manufacturer — brand supplied may vary ✓ Dimensions checked: ISO table and supplier data agreeRegular price
$40.60 USD
Regular price
Sale price
$40.60 USD
Unit price
per
Couldn't load pickup availability
Bore50 mm
1.9685 in
Outside dia.58 mm
2.2835 in
Width24 mm
0.9449 in
TypeDrawn cup needle roller bearing, open ends
SealingContact rubber seals, both sides
Flat-rate shipping — calculated by weight at checkout
Image is for illustration purposes only.
HK5024.-2RS specifications
| Specification | Metric | Inch | Basis |
|---|---|---|---|
| Bore (d) | 50 mm | 1.9685 in | ISO table for this designation, confirmed by supplier data |
| Outside diameter (D) | 58 mm | 2.2835 in | ISO table for this designation, confirmed by supplier data |
| Width (B) | 24 mm | 0.9449 in | ISO table for this designation, confirmed by supplier data |
| Bearing type | Drawn cup needle roller bearing, open ends | Stated by the designation | |
| Seals / shields | Contact rubber seals, both sides | Stated by the designation | |
HK5024.-2RS is a drawn cup needle roller bearing, open ends, 50 mm bore × 58 mm OD × 24 mm wide (1.9685 × 2.2835 × 0.9449 in). It has rubber contact seals on both sides.
The HK5024.2RS is a drawn cup needle roller bearing with double rubber seals (2RS) on both sides. This bearing features a thin-walled outer ring drawn from steel sheet, with needle rollers guided directly on a hardened shaft, providing a compact radial bearing solution with high load capacity in minimal radial space.
HK5024.2RS Double Sealed, Caged Drawn Cup Needle Roller Bearing, 50 mm Inner Diameter x 58 mm Outer Diameter x 24 mm Width
Measurement Type
Metric
Inner Diameter (ID)
50 mm
Outside Diameter (OD)
58 mm
Width
24 mm
Sealing
Double Sealed
Precision Class
ISO P0
Other Features
Drawn Cup Needle Roller Bearing | Radial Load Design | Sealed
Component
Roller Assembly with Outer Ring-No Inner Ring
Weight (kg)
0.081
Basic Number
HK5024
UNSPSC
31171512
