5313ZZ
Tier-one manufacturer — brand supplied may vary ✓ Verified against manufacturer sourcesCouldn't load pickup availability
Image is for illustration purposes only.
What 5313ZZ means
| Code | Position | Meaning |
|---|---|---|
53 |
Series | Series 53: angular contact ball bearing, double row, diameter series 3 (medium) |
13 |
Bore | Bore code 13 × 5 = 65 mm |
ZZ |
Closure | Metal shields, both sides |
Read from the ISO / ABMA numbering rules and the makers' published suffix conventions. Decode any other number with the bearing number decoder.
5313ZZ specifications
| Specification | Metric | Inch | Basis |
|---|---|---|---|
| Bore (d) | 65 mm | 2.5591 in | ISO table for this designation, confirmed by supplier data |
| Outside diameter (D) | 140 mm | 5.5118 in | ISO table for this designation, confirmed by supplier data |
| Width (B) | 58.74 mm | 2.3125 in | Maker's catalogue (PEER Bearing), confirmed by supplier data |
| Bearing type | Double row angular contact ball bearing | Stated by the designation | |
| Seals / shields | Metal shields, both sides | Stated by the designation | |
| Internal clearance | Normal (CN): no clearance code in the designation | Stated by the designation | |
| Cage | JIS S55C Steel | Supplier catalogue listing | |
| Tolerance class | Normal (ISO P0 / ABEC 1): no tolerance-class code | Stated by the designation | |
| Material | Jis suj2 steel | Supplier catalogue listing | |
5313ZZ is a double row angular contact ball bearing, 65 mm bore × 140 mm OD × 58.74 mm wide (2.5591 × 5.5118 × 2.3125 in). It has metal shields on both sides.
The 5313-ZZ is a double row angular contact ball bearing with metal shields on both sides and a 65mm bore diameter. The metal shield enclosure provides protection against contaminants while allowing for pre-lubrication in industrial applications.
Model Number: 5313 ZZ
Bore/Inner Diameter Inch: 2.5591
Bore/Inner Diameter mm: 65
Outside Diameter Inch: 5.5118
Outside Diameter mm: 140
Width Inch: 2.311
