Image is for illustration purposes only.
5310
Angular contact ball bearings are designed to accommodate combined radial and axial loads, with the contact angle enabling thrust load support in one direction. The open design without seals or shields allows for high-speed operation and ease of lubrication maintenance.
This bearing type is commonly used in machine tool spindles, automotive wheel hubs, pumps, and gearboxes where precise axial positioning and moderate to high-speed rotation under combined loading conditions are required.
Interchange / cross reference
TIMKEN 5310KETIMKEN 5310W
Cross-references are provided as a guide — verify dimensions and fit for your application.
For large orders ($2000+) please inquire by email.
Measurement Type
Metric
Inner Diameter (ID)
50 mm
Outside Diameter (OD)
110 mm
Width
44.4 mm
Sealing
Open
Precision Class
ABEC 1 | ISO P0
Series
53
Bearing Type
Angular contact ball bearing
Other Features
Double Row | Ball Bearing | Radial Load Design
Component
Assembly
Weight (kg)
1.81
Basic Number
5310
UNSPSC
31171504
